Hikvision DS-7104HGHI-ECO/M1 4 Channel Mini 1U DVR with H.265 Pro+

Reviews (0)
Sold: 0
Shop More

Product Code: PRD-80693 - 53

৳ 2,150.00

WhatsApp Inquiry

Category
CCTV Camera
Sub Category
DVR and NVR
Brand
HIKVISION

Key Features

Model: DS-7104HGHI-ECO/M1
H.265 Pro+/H.265 Pro/H.265 Video Compression
Up to 5-ch IP Camera Inputs (up to 2 MP)
Up to 1080p Lite@30 fps Encoding Capability
Max. 1200 m for 720p HDTVI Signal

Last Updated: 10 Jan, 2026

৳ 2,150.00

Quantity

Color

Add to cart

Details

Return policy: Eligible for Return, Refund or Replacement within 30 days of receipt Support: Free tech support included

Audio and Video
IP Camera Input	1-ch (up to 5-ch) Up to 1080p resolution Support H.265+/H.265/H.264+/H.264 IP cameras
Two-Way Talk	Reuse the first audio input
Display
Resolution	HDTVI Input: 1080p25, 1080p30, 720p25, 720p30 AHD Input: 1080p25, 1080p30, 720p25, 720p30 HDCVI Input: 1080p25, 1080p30, 720p25, 720p30 CVBS Input: Support HDMI Output: 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz VGA Output: 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
Recording
Compression	H.265 Pro+/H.265 Pro/H.265/H.264+/H.264
Resolution	For 1080p stream access: 1080p Lite/720p Lite/WD1/4CIF/VGA/CIF For 720p stream access: 720p/WD1/4CIF/VGA/CIF For SD stream access: WD1/4CIF/VGA/CIF
Record Rate	Main stream: For 1080p stream access: 1080p Lite/720p Lite/WD1/4CIF/VGA/CIF@25 fps(P)/30 fps (N) For 720p stream access: 720p/WD1/4CIF/VGA/CIF@ 25fps (P)/30 fps (N) For SD stream access: WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N) Sub-stream: 4CIF@15fps; CIF/QVGA@25 fps (P)/30 fps (N)
Bit Rate	32 Kbps to 4 Mbps
Others	Stream Type: Video, Video & Audio Audio Compression: G.711u Audio Bitrate: 64 Kbps
Video Detection And Alarm
Trigger Event	Deep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights; Quick search by object or event type is supported;
Alarm Input	N/A
Playback And Backup
Sync Playback	4-ch
Search Mode	Quick search by object or event type is supported
Network
Ethernet Port	1, RJ45 10/100 Mbps self-adaptive Ethernet interface
Network Function	TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, UPnP, HTTPS
Storage
Internal HDD	1 SATA interface Up to 4 TB capacity for each disk
Auxiliary Interface
USB	Rear panel: 2 × USB 2.0
Power
Power Supply	12 VDC, 1.5 A
Power Consumption	≤ 16 W (without HDD)
Component Environment
Operational Conditions	-10 °C to 55 °C (14 °F to +31 °F)
Construction
Dimensions	200 × 200 × 48 mm (7.9 × 7.9 × 1.9 inch)
Net Weight	≤ 0.8 kg (without HDD, 1.8 lb.)

The Hikvision DS-7104HGHI-ECO/M1 4 Channel Mini 1U DVR is a compact and efficient surveillance recording solution designed for modern CCTV systems. It supports HDTVI, AHD, HDCVI, and CVBS cameras, along with up to 5 IP cameras (maximum 2MP resolution), providing excellent system flexibility. With advanced H.265 Pro+ video compression, the DVR minimizes storage usage while maintaining clear and stable video quality.

This DVR delivers 1080p Lite real-time recording at up to 30 fps and supports long-distance transmission of up to 1200 meters for 720p HDTVI signals. Integrated Deep Learning-based Motion Detection 2.0 intelligently distinguishes humans and vehicles, significantly reducing false alarms. It features two-way audio reuse, simultaneous HDMI and VGA Full HD output, smooth 4-channel playback, and remote access via Hik-Connect. Supporting up to 4TB SATA HDD, low power consumption, and a compact metal design, it is ideal for home, office, and small business security applications.
